Tiskanje keramičnih akrilnih tiskalnikov z lakom

Specifikacije

Usage: Label Printer, Paper Printer
Plate Type: Gravure
Tip: brizgalni tiskalnik
Pogoj: Novo
Samodejna stopnja: Samodejno
Napetost: 110V / 220V
Dimensions(L*W*H): L3330*W1020*H760
Weight: 900kg
Garancija: 1 leto
Print Dimension: 2.5*1.23
Vrsta črnila: uv črnilo

Opis izdelka

Ime:	WER-ET2513UV
Class:	UVB series
Print technology:	Drop-on-demand Piezo electric
Tiskalna glava:	4/5/7/8(Konica 1024I/7 pl)
Print size:	2.50m*1.26m
Print height:	10cm
Resolucija:	1440dpi max
Hitrost:	4pass 60sqm/h ; 6pass 40sqm/h ; 8pass 30sqm/h
Locating mode:	Raster /servo
Barva:	CMYK W LC LM
Media width:	2.50m*1.60m
Media handle:	Sheet to sheet
Media types:	KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
Drying system:	UV žarnica
File format:	TIFF,Postscript 3,JPEG,EPS,PDF
Working process:	Printmon software for windows xp/ windows7
Rip:	Photoprint /maintop
Power supply:	50hz/60hz 220v(10%)20A
Operation enviroment:	(Temperature )18-26(Humidity )40%-70%
Dimension:	4.6m2.3m1.65m
Utež:	1200KG

Prednosti

(1)Use Konica 1024I printhead, Hyperfine printing and high efficiency with 1440dpi;
(2) LED UV žarnica brez predgretja čevlja v teku, z dolgo življenjsko dobo, prihranek časa in energije;
(3) UV črnila, okolje in brez vonja sprostitev, instant sušenje, in ne zlahka zbledi;
(4)Can use white ink, with self circulation and self shaking function, avoid the white ink to be precipitate and stocking the printhead;
(5)The media can be 100mm, if higher can be customized;
(6) lahko natisne 25sqm / h, in stroški za črnilo bi bilo okoli 1,5 dolarjev;
(7)The power is 1100W only, low power, save energy.

Aplikacije

Printed materials could be: glass, ceramic, ceiling, aluminum sheet, wood board, door sheet, metal panel, billboard, acrylic panel,
Plexiglass, paper board, foam board, PVC expansion board, corrugated cardboard; flexible materials such as PVC, canvas, cloth,
carpet, sticky note, reflective film, leather etc. all kinds sheet materials and coiled materials.

Application areas

Decoration industry, glass industry, sign industry, exhibition industry, rigid paperboard packing industry, leather, art-ware industry,
furniture industry etc.

naše storitve

1.One year warranty and technician is available overseas. Lifetime maintenance for printer
2.Free to change all the spares except easily broken spares like printhead, ink supplying system etc
3.Free training and free printer installing, but need afford accommodation&air ticket&visa if serve on site
4.Provide one set ink free and one free spares parts with printer together
5.Free software update for client in the future if need
6.Online after-sales-service by Email,Skype,QQ,MSN,phone etc with English speaking engineer

Pogosta vprašanja

V1. Ali zagotavljate garancijo za brizgalne tiskalnike?
We supply 1.5 year(18 months) free warranty for the electric boards. Within 1.5 year, if the boards have any problems, please send the defective board to us and we will repair it soon without charging. (Printhead and consumable parts are not included.)

Q2. What kind of after-sales- service do you have for WER?
A. We have 16 experienced engineers and 1 technical online customer service to supply 18-hour online service. If you have any problems, we can solve them online via skype and WhatsApp.
B. Storitev daljinskega krmiljenja s pomočjo programske opreme Team Viewer je na voljo uporabniku, da namesti programsko opremo in prilagodi program.
C. Prvič bo na voljo brezplačen tečaj za pomoč strankam pri namestitvi in vzdrževanju tiskalnika. Če stranka potrebuje, lahko pošljemo naše inženirje v tujino za zagotavljanje storitev, kot so postavitev in popravilo stroja. Na voljo je tudi brezplačno usposabljanje za vaše osebje.

Q3. Does the printing machine have the printing video?
We have uploaded the machine printing video in YouTube; if you want to see the printing effect, please contact me for Video links

Q4.Payment terms and delivery date?
Payment terms: we accept the T/T transfer, Western Union, telegram, also L/C.
Dobavni rok: za blago na zalogi, v 2 delovnih dneh po prejemu celotnega plačila.

V5. Ali je stroj opremljen s programsko opremo?
Stroj je že opremljen s programsko opremo za nadzor in programsko opremo RIP.

Q6. Kaj pa kakovost črnila?
Črnila, ki jih dobavljamo, so visoke kakovosti, saj so v našem stroju večkrat preizkušeni, zato se težave, kot so tiskalna glava z marmorjem ali slab tiskalni učinek, ne bodo pojavile. Če pride do problema s črnilom, ga bomo kmalu ocenili in potem prevzeli odgovornost, če je to naša krivda.

V7. Lahko pošljete črnilo DHL-u?
Yes, we can send ink by DHL.
For small quantity, we can send products by DHL; for large quantity, we suggest customer considering sea transport due to lower cost.

Q8. Ali ponujate vzorce črnila za testiranje?
Ponujamo brezplačne vzorce (1 liter črnila), medtem ko morajo stroški dostave plačati kupci.
